Industrial Nickel Alloy Seamless Pipe Tube DN6-DN1200 ASTM B163 Ni68cu28fe Monel400 N04400 W.Nr.2.4360 for Multiple Uses

Large Image : Industrial Nickel Alloy Seamless Pipe Tube DN6-DN1200 ASTM B163 Ni68cu28fe Monel400 N04400 W.Nr.2.4360 for Multiple Uses

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	NXF
Model Number:	Ni68cu28fe Monel400

Payment & Shipping Terms:

Minimum Order Quantity:	500 kilograms
Price:	$18.00/kilograms 500-999 kilograms

Contact Now

Detailed Product Description

Type:	Nickel Pipe	Application:	Industry
Grade:	ASTM B163 Monel400	Ni (Min):	89.9%
Resistance (μΩ.m):	NA	Powder Or Not:	Not Powder
Ultimate Strength (≥ MPa):	650	Elongation (≥ %):	30
Name:	Nickel Alloy Pipe	Material:	ASTM B163 MONEL UNS N04400
Outer Diamete:	DN6-DN1200	Thickness:	SCH10-SCH XXS
Standard:	ASTM, BV/ABS/LR/TUV/DNV/BIS/PED	Length:	6-12M
Processing Servic:	Cutting	Surface Treatment:	Bright Soft
Delivery Time:	10-25 Days	MOQ:	1piece

Product Description

Monel400 is the corrosion-resistant alloy with the largest amount, the most versatile and excellent comprehensive performance. The alloy has excellent corrosion resistance in hydrofluoric acid and fluorine gas media, and excellent corrosion resistance to hot concentrated alkali liquor. It is also resistant to corrosion by neutral solutions, water, sea water, atmosphere, organic compounds, etc. An important feature of this alloy is that stress corrosion cracking is generally not produced and the cutting performance is good.

Specification

Monel 400 Chemical composition

Alloy	%	Ni	Cu	Fe	C	Mn	Si	S
Monel400	Min.	63	28
Monel400		Max.		34	2.5	0.3	2	0.5	0.024

Monel 400 Physical properties

Density	8.83 g/cm³
Melting point	1300-1390 °C

Monel 400 Alloy minimum mechanical properties in the room temperature

Alloy state	Tensile strength Rm N/mm²	Yield strength R P0. 2 N/mm²	Elongation A 5 %
Monel400	480	170	35

Specification

Monel Form	Size
Monel Spring wire	0.08mm-10mm
Monel plate	0.3mm-15mmX1000mmX L
Monel strip	0.06mm-2.0mmX 200mm X L
Monel Rod	8mm-40mm X L
Monel welding wire	1.2mm, 1.6mm, 2.0mm

Monel 400 Application field
Monel 400 alloy is a multi-purpose material in many industrial applications:
1. Seamless water pipe in the power factory
2. Sea-water exchanger and evaporator
3. Sulfuric acid and hydrochloric acid environment
4. Crude distillation
5. Sea-water in the use of equipment and propeller shaft
6. Nuclear industry and used in the manufacture of uranium enrichment isotope separation equipment
7. Manufacturing hydrochloric acid equipment used in the production of pump and valve

Packing & Delivery

Packaging Details:Plastic film inside , wooden pallets outside , choose the suitable packing,Alos it can be customized by the clients' demand.

Delivery detail:According to the quantities and specifications of each order.Normal delivery time is from 30 to 45 days after receiving the deposit.

Company Profile

New XiFei (SuZhou) Business Co.,Ltd is one of the leading and most respected manufacturers in China. Our products include metals, machinery, containers, construction materials, mechanical products, electrical systems, and medical accessories. Established in 1980, XIFEI has been working diligently ever since to embrace the needs of our global customer base.We work to ensure absolute customer satisfaction. Our team has dedicated itself to perfecting our three core components, "Service, Management and Craftsmanship."

1. Are you trading company or manufacturer ?
We are manufacturer.

2. How long is your delivery time?
Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.

3. Do you provide samples ? is it free or extra ?
Yes, we could offer the sample for free charge but need pay the cost of freight.

4. What is your terms of payment ?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shippment.
