Nickel Chromium Iron Alloy Pipe for Industrial NXF GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA Inconel X750 Seamless Pipe

Large Image : Nickel Chromium Iron Alloy Pipe for Industrial NXF GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA Inconel X750 Seamless Pipe

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	NXF
Model Number:	Pipe

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$14.99/pieces 10-99 pieces

Contact Now

Detailed Product Description

Type:	Nickel Pipe, Seamless	Application:	Space Flight And Aviation/Energy/Chemical Engineer
Grade:	GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA	Ni (Min):	63%
Resistance (μΩ.m):	1.22x10-6μΩ.m	Powder Or Not:	Not Powder
Ultimate Strength (≥ MPa):	890-1110MPa	Elongation (≥ %):	25%-30%
Product Name:	Inconel X750 Alloy Pipe	Material:	GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA
Standard:	UNS	OD:	Customizable
Thickness:	Customizable	Length:	Customizable
Brand:	NXF	Packing:	Wooden Case
MOQ:	1pc

Product Description

Inconel X-750 alloy is mainly a γ "[Ni3(Al, Ti, Nb)] phase aging strengthened nickel based superalloy, with good corrosion
resistance and oxidation resistance below 980℃, high strength below 800℃, and good relaxation resistance below 540℃. It also has good formability and weldability. The alloy is mainly used in the manufacture of plane springs and helical springs that are resistant to relaxation and require high strength for aircraft engines operating below 800 ° C. It can also be used to manufacture turbine turbine blades and other parts. The varieties available are sheet, strip, bar, forgings, rings, wire and tubing.

Pipe generally refers to the pipe fittings used to transport various fluids in the pipeline. Common cast iron pipe, steel pipe, non-ferrous metal pipe, non-metallic pipe, plastic pipe and so on. Generally, the pipe is usually round, and there are also shaped tubes made of non-circular cross sections. There are many materials for making pipes, and metals such as steel, iron and copper are commonly used.

Steel pipe is the most widely used pipe with high strength, smooth surface and good technology (can be welded, cut and bent). Steel pipes are divided into two categories: welded steel pipes and seamless steel pipes. Water and gas steel pipe is a kind of welded steel pipe with longitudinal straight weld, which is divided into ordinary type and reinforced type according to the thickness of the pipe wall, the caliber is generally 5 ~ 150 mm, and the nominal pressure is not more than 1.6 mpa. The two ends of this steel pipe are available with and without threads. The surface of the steel pipe also has two kinds of galvanized and non-galvanized. Galvanized steel pipe is commonly called white iron pipe, which is more corrosion resistant and is widely used in water supply pipes. The diameter of spiral welded steel pipe is generally 100 ~ 700 mm, mostly used for heating, gas and oil pipelines, and the largest diameter of welded steel pipe for long-distance transmission of oil and natural gas has exceeded 1500 mm. The wide range of seamless steel pipe materials and wall thickness is widely used in various pressure pipes, and the caliber is generally 4 to 630 mm. In addition to being used as pressure pipes in power engineering, chemical industry, petroleum industry and other sectors, seamless steel pipes are also important structural materials for aircraft, ships, drilling RIGS and bicycles.

Specification

item	value
Warranty	3 years
Customized support	OEM, ODM
Place of Origin	China
	Jiangsu
Brand Name	NXF
Model Number	Inconel X750 Alloy Pipe
Connection	Welding
Shape	Equal
Head Code	Round
Product name	Inconel X750 Alloy Pipe
Material	GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA
Standard	UNS
OD	Customizable
Thickness	Customizable
Length	Customizable
Type	Seamless Pipe
Brand	NXF
Packing	Wooden Case
MOQ	1pc

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Customer Visit

New XiFei (SuZhou) Business Co.,Ltd is one of the leading and most respected manufacturers in China. Our products include metals, machinery, containers, construction materials, mechanical products, electrical systems, and medical accessories. Established in 1980, XIFEI has been working diligently ever since to embrace the needs of our global customer base.We work to ensure absolute customer satisfaction. Our team has dedicated itself to perfecting our three core components, "Service, Management and Craftsmanship." Our advantage:3S Service(Small Quantity/Short Time/Special Material)

Certifications

1. who are we?
We are based in Jiangsu, China, start from 2021,sell to South Asia(30.00%),Eastern Asia(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%),Domestic Market(5.00%),North America(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pipe,Flange,Steel plate,Pipe fittings,Alloy products

4. why should you buy from us not from other suppliers?
Our advantage:3S Service (Small Quantity/Short Time/Special Material) We have our own factories, quality can be controlled seriously. We Specialize in manufacturing about 21 years. We have professional testing department and testing equipment.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CAD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
