Round Head Code Inconel601 Tee SCH80-XXS DN6-DN100 Customizable Weld 20mm 25mm DN6-DN100 Casting Technics NiCr23Fe NC23FeA

Large Image : Round Head Code Inconel601 Tee SCH80-XXS DN6-DN100 Customizable Weld 20mm 25mm DN6-DN100 Casting Technics NiCr23Fe NC23FeA

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	NXF
Model Number:	DN6-DN100

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$5.00/pieces 10-99 pieces

Contact Now

Detailed Product Description

Warranty:	3 Years	Customized Support:	OEM
Technics:	Casting	Connection:	Welding
Shape:	Reducing	Head Code:	Round
Product Name:	Inconel601 Tee	Material:	NS313/UNS N06601/NiCr23Fe/NC23FeA
Standard:	UNS	OD:	DN6-DN100
Thickness:	SCH80-XXS	Size:	Customizable
Type:	Welding	Brand:	NXF
Packing:	Wooden Case	MOQ:	1pc

Product Description

Inconel nickel-chromium-iron alloy 601 (UNS N06601 / W.Nr. 2.4851) is a general-purpose engineering material for applications that require resistance to heat and corrosion. An outstanding characteristic of INCONEL alloy 601 is its resistance to hightemperature oxidation. The alloy also has good resistance to aqueous corrosion, has high mechanical strength, and is readily formed, machined and welded. The composition is a facecentered- cubic solid solution with a high degree of metallurgical stability. The alloy's nickel base, in conjunction with substantial chromium content, provides resistance to many corrosive media and hightemperature environments. Oxidation resistance is further enhanced by the aluminum content.

The properties of INCONEL alloy 601 make it a material of broad utility in such fields as thermal processing, chemical processing,pollution control, aerospace, and power generation.
Alloy 601 is a standard material of construction for various types of thermal-processing equipment. Industrial-heating
applications include baskets, trays, and fixtures for annealing, carburizing, carbonitriding, nitriding and other heat-treating
operations. In industrial furnaces, the alloy is used for radiant tubes, muffles, retorts, flame shields, strand-annealing tubes,woven-wire conveyor belts, chain curtains, burner nozzles, and electrical resistance heating elements. Other thermal-processing applications are thermocouple protection tubes, furnace-atmosphere generators, and infrared radiant screens.
Chemical-processing applications for alloy 601 include process heaters, condenser tubes in sour-water strippers, and insulating cans in ammonia reformers. The alloy is also used for combustor components and catalyst grid supports in equipment for nitric acid production.
In petrochemical processing, the alloy is used for catalyst regenerators and air preheaters in the manufacture of high-density polyethylene. In pollution-control applications, INCONEL alloy 601 is used for thermal reactors in exhaust systems of gasoline engines and for combustion chambers in solidwaste incinerators. In the power-generation field, alloy 601 is used for superheater tube supports, grid barriers, and ashhandling systems.
The alloy is also used for jet-engine igniters and for combustion-can liners, diffuser assembles, and containment rings in gas turbines for aircraft, industrial, and vehicular applications.

Mechanical Properties
INCONEL alloy 601 has good mechanical strength. As indicated by those values, the strength level exhibited by the alloy varies with the form and condition of the material.
The optimum condition for alloy 601 depends on the type of application and the service temperature involved. In general, the solution-treated condition is used for rupture-limited applications (temperatures of about 1000°F (540°C) and higher). The annealed condition is normally used for tensile-limited applications (temperatures below about 1000°F (540°C)).

Corrosion Resistance
The substantial nickel and chromium contents of INCONEL alloy 601 in conjunction with its content of aluminum give the alloy superior resistance to high temperature corrosion mechanisms. Of particular significance is its resistance to oxidation at temperatures up to 2200°F (1200°C). By virtue of its contents of chromium and aluminum, alloy 601 offers unique resistance to oxide spalling under cyclic thermal conditions.

Specification

item	value
Warranty	3 years
Place of Origin	China
	Jiangsu
Brand Name	NXF
Model Number	DN6-DN100
Technics	Casting
Connection	Welding
Shape	Reducing
Head Code	Round
Product name	Inconel601 Tee
Material	NS313/UNS N06601/NiCr23Fe/NC23FeA
Standard	UNS
OD	DN6-DN100
Thickness	SCH80-XXS
Size	Customizable
Type	Welding
Brand	NXF
Packing	Wooden Case
MOQ	1pc
