NXF GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA Inconel X750 BW Olet 1/8-24 INCH STD-SCH160 Forged Technique Customizable

Large Image : NXF GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA Inconel X750 BW Olet 1/8-24 INCH STD-SCH160 Forged Technique Customizable

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	NXF
Model Number:	1/8-24 INCH

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$5.00/pieces 10-99 pieces

Contact Now

Detailed Product Description

Warranty:	3 Years	Customized Support:	OEM
Technics:	Forged	Connection:	Welding
Shape:	Reducing	Head Code:	Round
Product Name:	Inconel X750 BW Olet	Material:	GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA
Standard:	UNS	OD:	1/8-24 INCH
Application:	Pipe Lines Connect	Pressure:	150-2500 Lb
Type:	Butt Welded	Brand:	NXF
Packing:	Wooden Case	MOQ:	1pc

Product Description

Inconel X-750 alloy is mainly a γ "[Ni3(Al, Ti, Nb)] phase aging strengthened nickel based superalloy, with good corrosion
resistance and oxidation resistance below 980℃, high strength below 800℃, and good relaxation resistance below 540℃. It also has good formability and weldability. The alloy is mainly used in the manufacture of plane springs and helical springs that are resistant to relaxation and require high strength for aircraft engines operating below 800 ° C. It can also be used to manufacture turbine turbine blades and other parts. The varieties available are sheet, strip, bar, forgings, rings, wire and tubing.

Butt Welding Olet is a branch pipe platform that has been widely used in recent years. It is a reinforced pipe fitting used for
branch pipe connection. It replaces the traditional branch pipe connection types such as reducing tees, reinforcement plates, and reinforced pipe sections. It has outstanding advantages such as safety and reliability, reduced cost, simple construction,improved medium flow channel, series standardization, and convenient design and selection. It is increasingly widely used in high-pressure, high-temperature, large-diameter, and thick-walled pipelines, replacing the traditional branch pipe connection method. The Olet body is made of high-quality forgings, and the materials used are the same as the pipeline materials, including carbon steel, alloy steel, and stainless steel. The branch pipe and the main pipe are welded. The connection between the branch pipe platform and the branch pipe or other pipes (such as short pipes, thread plugs, etc.), instruments, and valves has various types such as butt welding, socket welding, and threading. Standard: MSS SP 97, GB/T 19326, Pressure: 3000#, 6000#

Specification

item	value
Technics	Forged
Shape	Reducing
Head Code	Round
Place of Origin	China
	Jiangsu
Warranty	3 years
Customized support	OEM
Brand Name	NXF
Connection	Butt Welding
Product name	Inconel X750 Olet
Material	GH4145/UNS NO7750/NiCr15Fe7TiA/NC15TNbA
Standard	UNS
OD	1/8-24 INCH
Type	Butt Welding
Brand	NXF
Packing	Wooden Case
MOQ	1pc

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Production Equipment

Customer Visit

New XiFei (SuZhou) Business Co.,Ltd is one of the leading and most respected manufacturers in China. Our products include metals, machinery, containers, construction materials, mechanical products, electrical systems, and medical accessories. Established in 1980, XIFEI has been working diligently ever since to embrace the needs of our global customer base.We work to ensure absolute customer satisfaction. Our team has dedicated itself to perfecting our three core components, "Service, Management and Craftsmanship." Our advantage:3S Service(Small Quantity/Short Time/Special Material)

Certifications

1. who are we?
We are based in Jiangsu, China, start from 2021,sell to South Asia(30.00%),Eastern Asia(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%),Domestic Market(5.00%),North America(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pipe,Flange,Steel plate,Pipe fittings,Alloy products

4. why should you buy from us not from other suppliers?
Our advantage:3S Service (Small Quantity/Short Time/Special Material) We have our own factories, quality can be controlled seriously. We Specialize in manufacturing about 21 years. We have professional testing department and testing equipment.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CAD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
