Welding Slip-On Flange for DN15-1200 Class 150-1500 Pipe Fittings ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052

Large Image : Welding Slip-On Flange for DN15-1200 Class 150-1500 Pipe Fittings ASTM B574 B619 ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	NXF

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$4.00/pieces 10-49 pieces

Contact Now

Detailed Product Description

Standard:	ANSI, DIN, GB, ISO, JIS, Jpi, ASME, NXF	Product Name:	Slip-On Flange
Material:	ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052	OD:	DN 15-600
Class:	150-1500	Application:	Oil,Gas
Packing:	Wooden Box	MOQ:	1 Piece
Connection Method:	Weldng	Usage:	Oil Gas Water Industrial

Product Description

HASTELLOY C-4 alloy (UNS N06455) is the most (microstructurally) stable of the widely used nickel-chromium-molybdenum materials,which are well known for their resistance to many aggressive chemicals, in particular hydrochloric acid, sulfuric acid, and chlorides. This stability means that the alloy can be welded without fear of sensitization, i.e. the nucleation and growth of deleterious, second phase precipitates in the grain boundaries of the weld heat-affected zone (HAZ).Like other nickel alloys, it is ductile, easy to form and weld, and possesses exceptional resistance to stress corrosion cracking in chloride-bearing solutions (a form of degradation to which the austenitic stainless steels are prone). With its high chromium and molybdenum contents, it is able to withstand both oxidizing and non-oxidizing acids, and is resistant to pitting and crevice attack in the presence of chlorides and other halides.

Slip on flange is a common flange type, which has the advantages of simple production, low cost, and easy installation. Its structural feature is that the flange and the pipeline are connected together by welding, and the welding position is generally at the end of the pipeline. Flat welding flange has a simple structure, good flow performance, and can be applied to various media and pressure requirements. It is widely used in pipeline connection and equipment manufacturing.The connection between the flat welding flange and the pipeline is to insert the pipe into the inner hole of the flange to the appropriate position first, and then lap weld. A flat welding butt welding flange is a flange with a neck and a round pipe transition and butt welded to the pipe. Butt welding flanges are not easy to deform, have good sealing, are widely used, have corresponding rigidity and elasticity requirements and reasonable butt welding thinning transition, the weld is far away from the joint surface, and the joint surface is free from welding temperature deformation.

Product processing

Specification

Head Code	Round
Customized support	OEM
Connection	Welding
Product name	Slip-On Welding Flange
Material	ALLOY C-4/W.NR 2.4610/UNS N06455/AWS 052
OD	DN 15-600
Class	150-1500
Application	Oil,Gas
Packing	Wooden Box
MOQ	1 Piece
Connection method	Weldng
Usage	Oil Gas Water Industrial

Packing & Delivery

Company Profile

Application Areas

Certifications

1. who are we?
We are based in Jiangsu, China, start from 2021,sell to South Asia(30.00%),Eastern Asia(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%),Domestic Market(5.00%),North America(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pipe,Flange,Steel plate,Pipe fittings,Alloy products

4. why should you buy from us not from other suppliers?
Our advantage:3S Service (Small Quantity/Short Time/Special Material) We have our own factories, quality can be controlled seriously. We Specialize in manufacturing about 21 years. We have professional testing department and testing equipment.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CAD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
