NXF Pipe Fittings DN 15-1200 SCH10-XXS ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 90° or 45° S/R Butt Welding Elbow

Large Image : NXF Pipe Fittings DN 15-1200 SCH10-XXS ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 90° or 45° S/R Butt Welding Elbow

Product Details:

Place of Origin:	China
Brand Name:	NXF
Certification:	ISO CE

Payment & Shipping Terms:

Minimum Order Quantity:	1Piece
Price:	Negotiation
Packaging Details:	Export Packaging
Delivery Time:	5-8 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	300ton/month

Contact Now

Detailed Product Description

Product Name:	Butt Welding Elbow	Material:	Alloy G-35/UNS N06035
OD:	DN 6-1200	Pressure:	Class 3000-9000
Brand:	NXF	MOQ:	1 Piece
Packing:	Wooden Box	Sample:	Provide Sample
Usage:	Oil Gas Water Industrial	Connection:	Butt Welding

Product Description

Designated as UNS N06035 or DIN 2.4643, Alloy G-35 is a nickel-chrimium-molybdenum alloy designed to resist “wet process” phosphoric acid, which is used in the production of fertilizers. Similar to Hastelloy G-30, G35 alloy also has excellent resistance to localized attack in the presence of chlorides, since this can be a problem beneath deposits in evaporators used to concentrate “wet process” phosphoric acid. Besides, it is much less susceptible to chloride-induced stress corrosion cracking than the stainless steels and nickel-chromium-iron alloys traditionally used in “wet process” phosphoric acid. Due to the high chromium content, Hastelloy G-35 is extremely resistant to other oxidizing acids, such as nitric, and mixtures containing nitric acid. It possesses moderate resistance to reducing acids, as a result of its appreciable molybdenum content, and, unlike other Ni-Cr-Mo alloys, it is very resistant to “caustic de-alloying” in hot sodium hydroxide.

Butt-welding elbow is a steel hot-pressed or forged elbow, and its connection form is to directly weld the elbow to the steel pipe. Butt-weld elbows can be divided into long radius butt-weld elbows and short radius butt-weld elbows according to their curvature radius. The curvature radius of the long radius butt-weld elbow is equal to 1.5 times the outer diameter of the pipe, that is, R=1.5D. The curvature radius of the short radius butt-weld elbow is equal to the outer diameter of the pipe, that is, R=1D. In the formula, D is the diameter of the butt-weld elbow, and R is the curvature radius. If there is no special instruction, a 1.5D elbow is generally selected.

Alloy G-35/UNS N06035 of Chemical composition and mechanical properties

Alloy G-35/UNS N06035 Butt Welding Elbow Drawing

NXF Pipe Fittings DN 15-1200 SCH10-XXS ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 90° or 45° S/R Butt Welding Elbow 1

Specification

Technics	Forged
Warranty	3 years
Customized support	OEM
Brand Name	NXF
Connection	Butt Welding
Product name	Butt Welding Elbow
Material	Alloy G-35/UNS N06035
MOQ	1 Piece
Package	Wooden Carton
OD	DN 15-1200

Packing & Delivery

NXF Pipe Fittings DN 15-1200 SCH10-XXS ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 90° or 45° S/R Butt Welding Elbow 7

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

NXF Pipe Fittings DN 15-1200 SCH10-XXS ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 90° or 45° S/R Butt Welding Elbow 9

Other Products

NXF Pipe Fittings DN 15-1200 SCH10-XXS ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 90° or 45° S/R Butt Welding Elbow 12

Application Areas

NXF Pipe Fittings DN 15-1200 SCH10-XXS ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 90° or 45° S/R Butt Welding Elbow 13

Certifications

1. who are we?
We are based in Jiangsu, China, start from 2021,sell to South Asia(30.00%),Eastern Asia(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%),Domestic Market(5.00%),North America(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pipe,Flange,Steel plate,Pipe fittings,Alloy products

4. why should you buy from us not from other suppliers?
Our advantage:3S Service (Small Quantity/Short Time/Special Material) We have our own factories, quality can be controlled seriously. We Specialize in manufacturing about 21 years. We have professional testing department and testing equipment.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CAD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
