NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges

Large Image : NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges

Product Details:

Place of Origin:	China
Brand Name:	NXF
Certification:	ISO CE

Payment & Shipping Terms:

Minimum Order Quantity:	1Piece
Price:	Negotiation
Packaging Details:	Export Packaging
Delivery Time:	5-8 works
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	300ton/month

Contact Now

Detailed Product Description

Product Name:	Blind Flanges	Material:	Alloy G-35/UNS N06035
OD:	DN 15-1200	Pressure:	Class 150-2500
Application:	Industry	Usage:	Oil Gas Water Industrial
MOQ:	1 Piece	Brand:	NXF
Packing:	Wooden Box	Connection Method:	Welding

Product Description

Designated as UNS N06035 or DIN 2.4643, Alloy G-35 is a nickel-chrimium-molybdenum alloy designed to resist “wet process” phosphoric acid, which is used in the production of fertilizers. Similar to Hastelloy G-30, G35 alloy also has excellent resistance to localized attack in the presence of chlorides, since this can be a problem beneath deposits in evaporators used to concentrate “wet process” phosphoric acid. Besides, it is much less susceptible to chloride-induced stress corrosion cracking than the stainless steels and nickel-chromium-iron alloys traditionally used in “wet process” phosphoric acid. Due to the high chromium content, Hastelloy G-35 is high to other oxidizing acids, such as nitric, and mixtures containing nitric acid. It possesses moderate resistance to reducing acids, as a result of its appreciable molybdenum content, and, unlike other Ni-Cr-Mo alloys, it is very resistant to “caustic de-alloying” in hot sodium hydroxide.

Blind flange is also called blind plate, and its correct name is flange cover. It is a flange without a hole in the middle, used to seal the pipe plug. There are many types of sealing surfaces, including flat surface, convex surface, concave-convex surface, tongue-and-groove surface, and ring connection surface.

Alloy G-35/UNS N06035 of Chemical composition and mechanical properties

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 0

Alloy G-35/UNS N06035 Socket Blind Flange Drawing NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 1

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 8

Product processing

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 10

Specification

Connection	Welding
Product name	Blind Flanges
Material	Alloy G-35/UNS N06035
OD	DN 15-600
Process	Class 150-2500
Usage	Oil Gas Water Industrial
Packing	Wooden Box
MOQ	1 Piece
Brand	NXF

Packing & Delivery

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 11

Company Profile

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 13

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 15

Application Areas

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 16

Certification

NXF DN 15-1200 Class150-2500 Product Type Pipe Fittings ASTM B581,ASTM B582,ASTM B619 Alloy G-35/UNS N06035 Blind Flanges 17

1. who are we?
We are based in Jiangsu, China, start from 2021,sell to South Asia(30.00%),Eastern Asia(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%),Domestic Market(5.00%),North America(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pipe,Flange,Steel plate,Pipe fittings,Alloy products

4. why should you buy from us not from other suppliers?
Our advantage:3S Service (Small Quantity/Short Time/Special Material) We have our own factories, quality can be controlled seriously. We Specialize in manufacturing about 21 years. We have professional testing department and testing equipment.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CAD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
