NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges

Large Image : NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges

Product Details:

Place of Origin:	China
Brand Name:	NXF
Certification:	ISO CE

Payment & Shipping Terms:

Minimum Order Quantity:	1Piece
Price:	Negotiation
Packaging Details:	Export Packaging
Delivery Time:	5-8 works
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	300ton/month

Contact Now

Detailed Product Description

Product Name:	Alloy X/2.4656/UNS N06002	Material:	Alloy G-35/UNS N06035
OD:	DN 15-1200	Pressure:	Class 150-2500
Application:	Industry	Usage:	Oil Gas Water Industrial
MOQ:	1 Piece	Brand:	NXF
Packing:	Wooden Box	Connection Method:	Welding

Product Description

Alloy X has excellent resistance to reducing and carburizing atmospheres, making it suitable for furnace components. Due to its high molybdenum content, Alloy X may be subject to catastrophic oxidation at 1204°C.The alloy has good high temperature strength coupled with oxidation resistance up to 1093°C.This Alloy is readily weldable using matching filler wires. After severe forming, fabrications may be annealed at 1177°C, 15 minutes per 1/8″ of thickness, rapid air cool.A solid solution strengthening grade, Alloy X has good strength and corrosion resistance in reducing carburising atmospheres.

Weld Neck Flange is a kind of pipe fitting, which refers to a flange with a neck and a round tube transition and is connected to the pipe by butt welding. The butt-weld flange is not easy to deform, has good sealing, is widely used, has corresponding rigidity and elasticity requirements and reasonable butt welding thinning transition, the distance between the weld and the joint surface is large, and the joint surface is free from welding temperature deformation.The butt-weld flange is a kind of pipe fitting, which refers to a flange with a neck and a round tube transition and is connected to the pipe by butt welding. The butt-weld flange is not easy to deform, has good sealing, is widely used, has corresponding rigidity and elasticity requirements and reasonable butt welding thinning transition, the distance between the weld and the joint surface is large, and the joint surface is free from welding temperature deformation.

Alloy X/2.4656/UNS N06002 of Chemical composition and mechanical properties

NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges 0

Alloy X/2.4656/UNS N06002 Weld Neck Flange Drawing

NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges 1

Product processing

NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges 10

Specification

Technics	Forged
Connection	Welding
Product name	Weld Neck Flanges
Material	Alloy X/2.4656/UNS N06002
Connection method	Welding Connecting
Application	Oil,Factory
Packing	Wooden Box Packing
OEM	Provide OEM Services
MOQ	1 Piece
Sample	Provide Samples
Pressure	Class 150-2500

Packing & Delivery

NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges 11

Company Profile

NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges 13

Application Areas

NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges 16

Certification

NXF Manufacture Customizable ASTM B435,ASTM B572 Class 150-2500 Alloy X/2.4656/UNS N06002 Weld Neck Flanges 17

1. who are we?
We are based in Jiangsu, China, start from 2021,sell to South Asia(30.00%),Eastern Asia(10.00%),Mid East(10.00%),Eastern Europe(10.00%),South America(10.00%),Domestic Market(5.00%),North America(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),Southeast Asia(5.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Pipe,Flange,Steel plate,Pipe fittings,Alloy products

4. why should you buy from us not from other suppliers?
Our advantage:3S Service (Small Quantity/Short Time/Special Material) We have our own factories, quality can be controlled seriously. We Specialize in manufacturing about 21 years. We have professional testing department and testing equipment.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA；
Accepted Payment Currency:USD,EUR,CAD,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A;
Language Spoken:English,Chinese
